Hot-swapharddiskdrivestatusLEDs
Eachhot-swapharddiskdrivehastwostatusLEDsonthefront.
Figure23.3.5-inchhot-swapharddiskdrivestatusLEDs
Figure24.2.5-inchhot-swapharddiskdrivestatusLEDs
1HarddiskdriveactivityLED2HarddiskdriveRAIDstatusLEDDescription
OffOff
Theharddiskdrivehasfailedoris
notpresent.
On,greenOff
Theharddiskdriveispresentbutnot
inuse.
Blinking,green
Off
Theharddiskdriveisactiveanddata
isbeingtransferred.
On,greenBlinkingrapidly(aboutfourashes
persecond),amber
TheRAIDcontrollerisidentifyingthe
harddiskdrive.
On,greenOn,amber
TheRAIDarrayhasfailedandcannot
berecovered.Youneedtorecreatea
newarray.
Blinking,green
Blinkingslowly(aboutoneashper
second),amber
Theharddiskdriveisbeingrebuilt.
