Componentsofservermodelswith2.5-inchharddiskdrivebays
Figure22.Componentsofservermodelswith2.5-inchharddiskdrivebays
1Coolingshroud13Slimopticaldrive(availableinsomemodels)
2Powersupplycoolingshroud
14Diagnosticmodule(variesbymodel)
3Risercardassembly2
15Rackhandle(left)
4Oneortwohot-swapredundantpowersupplies
16Frontpanelboard
5PCIExpresscard(s)(availableinsomemodels)17Systemfans(4)
6Heatsink(s)withmicroprocessor(s)underneath18CPU1DIMMs(varybymodel)
7Backplane(s)forservermodelswith2.5-inch
harddiskdrivebays
19CPU2DIMMs(varybymodel)
8Rackhandle(right)20Systemboard
92.5-inchharddiskdrivearea(rightcage)21Systemboardbattery
102.5-inchharddiskdrivearea(middlecage)22PCIExpresscard(s)(availableinsomemodels)
11Pull-outinformationcard
23Risercardassembly1
12VGADB-15connector
34ThinkServerRD430UserGuide
