Componentsofservermodelswith123.5-inchharddiskdrivebays
Figure21.Componentsofservermodelswith123.5-inchharddiskdrivebays
1Coolingshroud
10Backplaneforservermodelswith123.5-inchharddisk
drivebays
2Powersupplycoolingshroud
11Systemfans(4)
3Risercardassembly2
12CPU1DIMMs(varybymodel)
4Oneortwohot-swapredundantpowersupplies13CPU2DIMMs(varybymodel)
5PCIExpresscard(s)(availableinsomemodels)14Systemboard
6Heatsink(s)withmicroprocessor(s)underneath15Systemboardbattery
7Rackhandle(right)withfrontcontrolsandLEDs
16Expandercard
83.5-inchharddiskdrivearea17RAIDcard
9Rackhandle(left)withfrontUSBconnectors
18Risercardassembly1
Chapter3.Productoverview33
