Componentsofservermodelswitheight3.5-inchharddiskdrivebays
Figure20.Componentsofservermodelswitheight3.5-inchharddiskdrivebays
1Coolingshroud
12Pull-outinformationcard
2Powersupplycoolingshroud
13Rackhandle(left)
3Risercardassembly214Frontpanelboard
4Oneortwohot-swapredundantpowersupplies
15Backplaneforservermodelswitheight3.5-inchharddisk
drivebays
5PCIExpresscard(s)(availableinsomemodels)16Systemfans(4)
6Heatsink(s)withmicroprocessor(s)underneath17CPU1DIMMs(varybymodel)
7Slimopticaldrive(availableinsomemodels)18CPU2DIMMs(varybymodel)
8Rackhandle(right)19Systemboard
93.5-inchharddiskdrivearea
20Systemboardbattery
10Diagnosticmodule(variesbymodel)21PCIExpresscard(s)(availableinsomemodels)
11VGADB-15connector
22Risercardassembly1
32ThinkServerRD430UserGuide
