3Mini-SASports4-7
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.
4Mini-SASports0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
5Signalcableconnector
UsedtoconnectthesignalcableforthefrontUSBconnectorsontheleftrackhandle.
678-pinpowerconnector
Usedtoconnectapowercabletoprovidepowertothebackplane.
Backplaneforservermodelswith2.5-inchharddiskdrivebays
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodelswith
2.5-inchharddiskdrivebays.
Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswith2.5-inchhard
diskdrivebays.
Figure32.Frontviewofthebackplaneforservermodelswith2.5-inchharddiskdrivebays
1Slot0fora2.5-inchharddiskdriveorsolid-state
drive
5Slot4fora2.5-inchharddiskdriveorsolid-statedrive
2Slot1fora2.5-inchharddiskdriveorsolid-state
drive
6Slot5fora2.5-inchharddiskdriveorsolid-statedrive
3Slot2fora2.5-inchharddiskdriveorsolid-state
drive
7Slot6fora2.5-inchharddiskdriveorsolid-statedrive
4Slot3fora2.5-inchharddiskdriveorsolid-state
drive
8Slot7fora2.5-inchharddiskdriveorsolid-statedrive
Chapter3.Productoverview41
