Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•YoucaninstalltwoThinkServerRAIDSuperCapacitorModulesinyourserver.
•UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollowthose
instructionsinadditiontotheinstructionsinthistopic.
ToinstalltheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage61.
3.Removetheservercover.See“Removingtheservercover”onpage61.
4.Touchthestatic-protectivepackagethatcontainstheThinkServerRAIDSuperCapacitorModuleto
anyunpaintedsurfaceontheoutsideoftheserver.Then,taketheThinkServerRAIDSuperCapacitor
Moduleoutofthepackage.
5.LocatetheplaceforinstallingtheSuperCapacitorModuleintheserver.See“Servercomponents”
onpage25.
6.NotetheorientationoftheThinkServerRAIDSuperCapacitorModule.Then,lowertheSuperCapacitor
Moduleandgentlyslideituntilitissecuredbythemountingstudsonthechassis.
Note:Dependingonyourservermodel,refertooneofthefollowingillustrationsbelow.
Figure59.InstallingtheThinkServerRAIDSuperCapacitorModule
7.ConnecttheThinkServerRAIDSuperCapacitorModuletoaRAIDcard.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage152.
RemovingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage59.
Chapter6.Replacinghardware93
