5.Slidethenewhot-swapharddiskdriveintothedrivebayfromthefrontuntilitsnapsintoposition
andthencompletelyclosethehandle.
Figure98.Installingthehot-swapharddiskdrive
6.Checkthehot-swaphard-disk-drivestatusLEDstoensurethattheharddiskdriveisoperatingcorrectly.
Youmighthavetorestarttheserverforthenewlyinstalledharddiskdrivetoberecognized.See
“Hot-swap-drivestatusLEDs”onpage43
.Iftheharddiskdriveisfaulty,youneedtoreinstallor
replaceituntilitisoperatingcorrectly.
7.Dooneofthefollowing:
•Ifyouareinstallingahot-swapharddiskdrive,savetheremoveddummyhard-disk-drivetrayincase
thatyoulaterremovethehot-swapharddiskdriveandneedadummytraytocoverthedrivebay.
•Ifyouarereplacingahot-swapharddiskdriveandareinstructedtoreturntheoldhot-swaphard
diskdrive,followallpackaginginstructionsanduseanypackagingmaterialsthataresuppliedto
youforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•ToconfigureRAID,goto“ConfiguringRAID”onpage54.
Installingorreplacinganeasy-swapdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage59.
Thistopicappliesonlytoservermodelsthathaveeasy-swapdrivesinstalled.See“Features”onpage7for
informationaboutthesupportedeasy-swapdrives.
ForalistofThinkServeroptions,goto:
http://lenovoquickpick.com/usa/home/thinkserver/rack-and-tower-server
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.The
numberoftheinstalleddrivesinyourservervariesdependingontheservermodel.Thevacantbaysare
eithercoveredbyanEMI-protectivepaneloroccupiedbydummytrays.Wheninstallingadrive,savethe
removeddummytrayincasethatyoulaterremovethedriveandneedthedummytraytocovertheplace.
Chapter6.Replacinghardware125
