2.Pressthereleasebutton1toopenthehandleofthehot-swapharddiskdriveorthedummytray.

Figure95.Openingthehandleofaharddiskdrive

Figure96.Openingthehandleofadummyhard-disk-drivetray

3.Pullthehandleandcarefullyslidethehot-swapharddiskdriveorthedummytrayoutofthefrontof

thechassis.

Figure97.Removingthehot-swapharddiskdriveorthedummytray

4.Touchthestatic-protectivepackagethatcontainsthenewhot-swapharddiskdrivetoanyunpainted

surfaceontheoutsideoftheserver.Then,takethenewhot-swapharddiskdriveoutofthepackage.

Note:Donottouchthecircuitboardontheharddiskdrive.

124ThinkServerRD550UserGuideandHardwareMaintenanceManual
