Figure116.Installingtheopticaldrive
8.Connecttheconnector1totherearoftheopticaldrive.
1
Figure117.Connectingtheconnector1totherearoftheopticaldrive
9.Ifnecessary,connecttheotherendofthesignalcabletotheSATAconnectorfortheopticaldriveon
thesystemboard.See“Systemboardcomponents”onpage36.
10.Ifyouareinstructedtoreturntheoldopticaldrive,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage152.
