LenovoThinkServerRAID510iAnyRAIDAdapter

TheLenovoThinkServerRAID510iAnyRAIDAdapterprovidesadvancedSATA/SAShardwareRAID

functions.Thefollowingillustrationshowstheconnectorsontheadapter.

Figure15.LenovoThinkServerRAID510iAnyRAIDAdapter

1PCI-E0connector

2PCI-E1connector

UsedtoconnecttotheAnyRAIDconnector0-1onthesystemboard.See“Systemboardcomponents”

onpage36.

3RAIDupgradekeyconnector

UsedtoconnectaThinkServerRAID510iupgradekey.

30ThinkServerRD550UserGuideandHardwareMaintenanceManual
