LenovoThinkServerRAID720iAnyRAIDAdapter
TheLenovoThinkServerRAID720iAnyRAIDAdapterprovidesadvancedSATA/SAShardwareRAID
functions.Thefollowingillustrationshowstheconnectorsontheadapter.
Figure16.ThinkServerRAID720iAnyRAIDAdapter
1ThinkServerRAIDSuperCapacitorModuleconnector(availableonsomemodels)
UsedtoconnecttotheThinkServerRAIDSuperCapacitorModule.See“Servercomponents”onpage25
.
2PCI-E0connector
3PCI-E1connector
UsedtoconnecttotheAnyRAIDconnector0and1onthesystemboard.See“Systemboardcomponents”
onpage36.
Chapter3.Productoverview31
