Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage152
.
InstallingorremovingtheSDmodule
IfyouequipyourserverwithanSDmodule,youcaninstalluptotwoSDcardsintotheSDmodulefordata
storage.YoucanpurchaseanSDmoduleandSDcardsfromLenovo.
ForalistofThinkServeroptions,goto:
http://lenovoquickpick.com/usa/home/thinkserver/rack-and-tower-server
InstallingtheSDmodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage59.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeSDmoduleandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToinstalltheSDmodule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage61.
3.Removetheservercover.See“Removingtheservercover”onpage61.
4.Removetherisercardassembly2.See“Replacingtherisercardassembly”onpage143.
5.LocatetheSDmoduleconnectoronthesystemboard.See“Systemboardcomponents”onpage36.
Removeanypartsanddisconnectanycablesthatmightimpedeyouroperation.
6.Touchthestatic-protectivepackagethatcontainstheSDmoduletoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheSDmoduleoutofthepackage.
Note:CarefullyhandletheSDmodulebyitsedges.
7.InserttheSDcardintotheSDcardslot.ThecardmightstopbeforeitiscompletelyinstalledintotheSD
module.Ensurethatyouinsertthecardfirmlyuntilyouhearaclick.
Chapter6.Replacinghardware83
