2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.
3.Removetheservercover.See“Removingtheservercover”onpage77.
4.IfyouareinstallingtheThinkServerRAIDSuperCapacitorModule,gotostep5.
IfyouarereplacingtheThinkServerRAIDSuperCapacitorModule,dothefollowing:
a.DisconnectthecableoftheThinkServerRAIDSuperCapacitorModulefromthePCIExpresscard.
Pressthetab1slightlyoutwardtoensurethatitcansmoothlypassthroughtheholeinthebracket
whenyouliftthebracket.Then,removethebracketwiththeThinkServerRAIDSuperCapacitor
Moduleasshown.
Figure104.RemovingtheThinkServerRAIDSuperCapacitorModulewiththebracketfromthecoolingshroud
b.Gentlypressthetab1onthebracketandremovetheThinkServerRAIDSuperCapacitorModule
fromthebracketatthesametime.
Figure105.RemovingtheThinkServerRAIDSuperCapacitorModulefromthebracket
5.Touchthestatic-protectivepackagethatcontainsthenewThinkServerRAIDSuperCapacitorModule
toanyunpaintedsurfaceontheoutsideoftheserver.Then,takethenewThinkServerRAIDSuper
CapacitorModuleoutofthepackage.
