6.NotetheorientationofthenewThinkServerRAIDSuperCapacitorModule.Then,gentlypressthetab
1onthebracketandinstallthenewThinkServerRAIDSuperCapacitorModuleintothebracketat
thesametime.
Figure106.InstallingtheThinkServerRAIDSuperCapacitorModuleintothebracket
7.PositionthenewThinkServerRAIDSuperCapacitorModulewiththebracketonthecoolingshroudso
thatonesideofthebracketissecuredbythetwotabs2.Then,presstheothersideofthebracket
straightdown.Ensurethatthetab
1passesthroughthecorrespondingholeinthebracketandsecures
thebracketinplace.
Figure107.InstallingtheThinkServerRAIDSuperCapacitorModulewiththebracketontothecoolingshroud
142ThinkServerRD640UserGuideandHardwareMaintenanceManual
