5.Dothefollowingtoconnecttheharddiskdrives:
a.12:ConnecttheSATAcomboconnectors0and1ofthemini-SASto2.5-inchSAScombocableto
theharddiskdrives0and1respectively.
b.3:Connectthepowerconnector1ofthemini-SASto2.5-inchSAScombocabletothe4-pinpower
connectorwhichisnearthememorymodulesonthesystemboard.
c.45:ConnecttheSATAcomboconnectors2and3ofthemini-SASto2.5-inchSAScombocableto
theharddiskdrives2and3respectively.
d.6:Connectthepowerconnector2ofthemini-SASto2.5-inchSAScombocabletotheother
available4-pinpowerconnectoronthesystemboard.
Formoreinformation,see“Systemboardcomponents”onpage32.
Figure14.Connectingthe2.5-inchharddiskdrives
6.Ifyouhaveaslimopticaldrive,installtheslim-optical-drivebracket,andtheninstalltheslimoptical
drive.See“Removingandreinstallingtheslim-optical-drivebracket”onpage82and“Installingthe
slimopticaldrive”onpage71
.
