Attention:AnunoccupieddrivebayorPCIcardslotwithoutacover,shield,dummytray,filler,orany
otherprotectionmightimpacttheEMIintegrityandcoolingoftheserver,whichmightresultinoverheating
orcomponentdamage.
Removingandreinstallingtherackhandles
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
Toremoveandreinstalltherackhandles,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.
3.Oneachsideoftheserver,removethetwoscrews1thatsecuretherackhandleandthenremovethe
rackhandlefromthechassis.
Figure26.Removingtherackhandles
4.Toreinstalleachrackhandle,ensurethatthescrewholesintherackhandlearealignedwiththe
correspondingholesinthechassis.Then,installthetwoscrewstosecuretherackhandle.
5.Goto“Completingthepartsreplacement”onpage106.
Removingandreinstallingthefanduct
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Toaccesssomeservercomponentsonthesystemboard,youmustremovethefanduct.Toensureproper
coolingandairflow,youmustreinstallthefanductbeforeturningontheserver.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Toremoveandreinstallthefanduct,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
Chapter6.Installing,removing,orreplacinghardware57
