6.PositiontheTR700BatteryabovetheThinkServerRAID700Adaptersothattheboard-to-board

connector

1onthebottomoftheTR700Batteryisalignedwiththeconnector2ontheThinkServer

RAID700Adapter;andthethreemountingstudsonthebottomoftheTR700Batteryarealignedwith

thecorrespondingholesintheThinkServerRAID700Adapter.CarefullypresstheTR700Batteryonto

theThinkServerRAID700Adapteruntilthetwoconnectors(

1and2)areﬁrmlyjoined.Then,installthe

threescrewsthatcomewiththeTR700BatteryoptionkittosecuretheTR700Batteryinplace.

Notes:

•Centerthescrewdriverwhenyouinstallthescrewsanddonotover-tightenthescrewstoavoid

possibledamagetoanyparts.

•DonottouchtheboardonthebottomoftheTR700Battery.

Figure39.InstallingtheTR700Battery

7.InstalltheThinkServerRAID700AdapterwiththeTR700Batteryontherisercardassembly.See

“InstallingorremovingtheRAIDcard”onpage62.

8.Reinstalltherisercardassembly.See“Replacingtherisercardassembly”onpage75.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage106.

RemovingtheTR700Battery

Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”

onpageiii

and“Guidelines”onpage53.

Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother

computerforreference.

Notes:

•IfyouremovetheTR700Battery,youwilllosethebackuppowerfortheThinkServerRAID700Adapter.

•UseanydocumentationthatcomeswiththeTR700Batteryandfollowthoseinstructionsinadditionto

theinstructionsinthistopic.

ToremovetheTR700Battery,dothefollowing:

70ThinkServerRS140UserGuideandHardwareMaintenanceManual
