Figure60.Installingthe2.5-inchharddiskdrivetogetherwiththebracket
10.ConnecttheSATAcomboconnectortothe2.5-inchharddiskdrive.See“Connectingthecables”
onpage22.
11.Ifyouareinstructedtoreturntheold2.5-inchharddiskdrive,followallpackaginginstructionsanduse
anypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage106
.
Replacinga3.5-inchharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Note:ThisproceduremustbeperformedonlybytrainedservicepersonnelofLenovo.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourservermightcomewith3.5-inchharddiskdrives,2.5-inchharddisk
drives,or2.5-inchsolid-statedrives.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
•Useanydocumentationthatcomeswiththeharddiskdriveandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ForalistofThinkServerharddiskdriveoptions,goto:
http://www.lenovo.com/thinkserver
Beforeyoubegin,reviewthefollowingharddiskdriveinstallationrules:
•Followtheorderofthehard-disk-drivebayswheninstallingaharddiskdrive.See“Servercomponents”
onpage17
tolocatethehard-disk-drivebaysinyourserver.
•ForRAIDconfiguration,theharddiskdrivesmustbethesametypewiththesamecapacityiftheyare
withinasingleRAIDarray.Formoreinformation,see“UsingtheSetupUtilityprogram”onpage37.
Chapter6.Installing,removing,orreplacinghardware87
