•Forharddiskdriveswithdifferentcapacities,installtheharddiskdrivebyfollowingtheorderofthe
hard-disk-drivebaysaswellastheorderfromthelowestcapacitytothehighestcapacity.
Toreplacea3.5-inchharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.Locatetheappropriate3.5-inchharddiskdrivethatyouwanttoreplace.See“Servercomponents”
onpage17.
Note:Ifyouwanttoremovethe3.5-inchharddiskdrivethatisinstalledundertheslim-optical-drive
bracket,removetheslim-optical-drivebracketfirst.See“Removingandreinstallingtheslim-optical-drive
bracket”onpage82
.
5.DisconnecttheSATAcomboconnectorfromthe3.5-inchharddiskdrivethatyouwanttoreplace.
6.Liftthereleasepin1ofthe3.5-inchhard-disk-drivebracket.Then,slidethe3.5-inchharddiskdrive
withthebracketasshowntoreleasethebracketfromtheserver.Liftthe3.5-inchdrivetogetherwiththe
bracketoutofthechassis.
