Internalcomponents
Figure7“Componentlocations”onpage18showsthelocationsofthevariouscomponentsinyourserver.
Toremovetheservercoverandaccesstheinsideoftheserver,see“Removingtheservercover”onpage41.
Figure7.Componentlocations
1Heatsinkandfanassembly7Frontfanassembly
2Microprocessor8Harddiskdrive
3Memorymodule
9Systemboard
4Opticaldrive10Graphicscard(availableinsomemodels)
5Cardreaderdrivebay
11Rearfanassembly
6Frontbezel12Powersupplyassembly
Internaldrives
Internaldrivesaredevicesthatyourserverusestoreadandstoredata.Youcanadddrivestoyourserver
toincreasestoragecapacityandenableyourservertoreadothertypesofmedia.Internaldrivesare
installedinbays.
18ThinkServerTS140HardwareMaintenanceManual
