2.Removetheservercover.See“Removingtheservercover”onpage41.
3.Locatethesystemboardbattery.See“Locations”onpage12.
4.Removetheoldsystemboardbattery.
Figure68.Removingtheoldsystemboardbattery
5.Installthenewsystemboardbattery.
Figure69.Installingthenewsystemboardbattery
6.Reinstalltheservercoverandconnectthecables.See“Completingthepartsreplacement”onpage90.
Note:Whentheserveristurnedonforthefirsttimeafterthebatteryisreplaced,anerrormessage
mightbedisplayed.Thisisnormalafterreplacingthebattery.
7.Turnontheserverandallattacheddevices.
8.UsetheSetupUtilityprogramtosetthedate,time,andanypasswords.SeeChapter5“Configuring
theserver”onpage23
.
9.Disposeofthefailingbatteryasrequiredbylocalordinancesorregulations.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage90.
Replacingthesystemboard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage39.
Thistopicprovidesinstructionsonhowtoreplacethesystemboard.
Note:ThisproceduremustbeperformedonlybytrainedservicepersonnelofLenovo.
CAUTION:
Theheatsinkandmicroprocessormightbeveryhot.Turnofftheserverandwaitthreetofiveminutes
tolettheservercoolbeforeremovingtheservercover.
Chapter6.Installing,removing,orreplacinghardware87
