Figure37.Removingtheharddiskdrivefromthecage
10.Toinstallanewslimopticaldriveandanewfourthharddiskdrive,see“Installingtheslimoptical
driveandthefourthharddiskdrive”onpage56.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage90.
InstallingorreplacingaPCIcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage39.
ThistopicprovidesinstructionsonhowtoinstallorreplaceaPCIcard.
YourserverhasonestandardPCIcardslot,onePCIExpressx1cardslot,onePCIExpressx4cardslot,and
onePCIExpressx16cardslot.
ToinstallorreplaceaPCIcard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage41.
62ThinkServerTS140HardwareMaintenanceManual
