Locatingpartsonthesystemboard

Figure6“Systemboardpartlocations”onpage17showsthelocationsofthepartsonthesystemboard.

Figure6.Systemboardpartlocations

1PS/2keyboardandmouseconnector14SATA3.0connectors0to4

24-pinpowerconnector

15Powerfanconnector

3Systemboardbattery16Frontpanelconnector(forconnectingtheLEDsandpower

buttononthefrontoftheserver)

4Microprocessor

17FrontUSB3.0connector(forconnectingtheUSBconnectors

onthefrontoftheserver)

5Microprocessorfanconnector

18FrontUSB2.0connector(forconnectinganadditionalUSB

device)

6Memoryslot1(DIMM1)19ClearCMOS(ComplementaryMetalOxideSemiconductor)

/Recoveryjumper

7Memoryslot2(DIMM2)20Serial(COM2)connector

8Memoryslot3(DIMM3)21PCIcardslot

9Memoryslot4(DIMM4)22PCIExpressx4cardslot

10Thermalsensorconnector

23PCIExpressx1cardslot

11Harddiskdrivefanconnector

24PCIExpressx16cardslot

124-pinSATApowerconnectors(2)25Systemfanconnector

1314-pinpowerconnector

26Coverpresenceswitchconnector(intrusionswitchconnector)

Chapter3.Productoverview17
