ConnectorDescription
VGAmonitorconnectorUsedtoattachaVGAmonitororotherdevicesthatuseaVGAmonitorconnector.
Ethernetconnector
UsedtoattachanEthernetcableforalocalareanetwork(LAN).
Note:TooperatetheserverwithinFCCClassBlimits,useaCategory5Ethernet
cable.
Figure5.EthernetstatusLEDs
EthernetstatusLED
ColorStatus
Description
Amber
On
Theconnectionspeedis1000Mbps.
GreenOn
Theconnectionspeedis100Mbps.
1Left:dataspeed
None
Off
Theconnectionspeedis10Mbps.
Yellow
On
TheserverisconnectedtoaLAN.
None
Off
TheserverisdisconnectedfromaLAN.
2Right:linkandactivity
YellowBlinkingTheLANisconnectedandactive.
