Lenovo ThinkServer TS140 70A0 User Manual

Figure4.Rearconnectorlocations
1Powercordconnector9Audioline-inconnector
2Serialconnector10PCIExpressx16graphicscard(availableinsomemodels)
3VGAmonitorconnector11PCIExpressx1cardslotbracket
4DisplayPortconnectors(2)12PCIcardslotbracket
5USB3.0connectors(4)13PCIExpressx4cardslotbracket
6USB2.0connectors(2)14Optionalserialconnector
7Microphoneconnector15Ethernetconnector
8Audioline-outconnector
16PS/2keyboardandmouseconnectors(optional)
ConnectorDescription
Audioline-inconnector
Usedtoreceiveaudiosignalsfromanexternalaudiodevice,suchasastereo
system.Whenyouattachanexternalaudiodevice,acableconnectstheaudio
line-outconnectorofthedevicetotheaudioline-inconnectoroftheserver.
Audioline-outconnector
Usedtosendaudiosignalsfromtheservertoexternaldevices,suchaspowered
stereospeakers(speakerswithbuilt-inamplifiers),headphones,multimedia
keyboards,ortheaudioline-inconnectoronastereosystemorotherexternal
recordingdevice.
DisplayPortconnector
Usedtoattachahigh-performancemonitor,adirect-drivemonitor,orotherdevices
thatuseaDisplayPortconnector.
Microphoneconnector
Usedtoattachamicrophonetoyourserverwhenyouwanttorecordsoundorif
youusespeech-recognitionsoftware.
Serialconnector
Usedtoattachanexternalmodem,aserialprinter,orotherdevicesthatusea
9-pinserialconnector.
USBconnectorUsedtoattachadevicethatrequiresaUSBconnector,suchasaUSBkeyboard,a
USBmouse,aUSBscanner,oraUSBprinter.IfyouhavemorethaneightUSB
devices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.
Chapter3.Productoverview15

Lenovo ThinkServer TS140 70A0 Specifications

General

Memory Slots	4 DIMM slots
Form Factor	Tower
Chipset	Intel C226
Processor	Intel Xeon E3-1200 v3 series
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5" or 2.5" HDD/SSD
RAID Support	RAID 0, 1, 10, 5
Network	Gigabit Ethernet
Network Controller	Intel I217LM
Expansion Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Power Supply	280W or 450W
Operating System Support	Windows Server, Red Hat, SUSE, VMware
