Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage90
.
Removingtheslimopticaldriveandthefourthharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage39.
Thistopicprovidesinstructionsonhowtoremovetheslimopticaldriveandthefourthharddiskdrive.
Toremovetheslimopticaldriveandthefourthharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage41.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage42.
4.Disconnectthesignalcablesandthepowercablesfromtheslimopticaldriveandthefourthhard
diskdrive.
5.Disconnectthecableofthefanforthefourthharddiskdrivefromtheharddiskdrivefanconnectoron
thesystemboard.See“Locatingpartsonthesystemboard”onpage17.
Note:Ifyourserverhasatertiaryharddiskdriveinstalled,disconnectthecableofthefanforthefourth
harddiskdrivefromthefanpowerconvertercable.
6.Pressthereleasebutton1andslidethecagewiththeslimopticaldriveandthefourthharddiskdrive
outofthefrontoftheserver.
Figure34.Removingthecagewiththeslimopticaldriveandthefourthharddiskdrive
60ThinkServerTS140HardwareMaintenanceManual

Lenovo ThinkServer TS140 70A0 Specifications

General

Memory Slots	4 DIMM slots
Form Factor	Tower
Chipset	Intel C226
Processor	Intel Xeon E3-1200 v3 series
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5" or 2.5" HDD/SSD
RAID Support	RAID 0, 1, 10, 5
Network	Gigabit Ethernet
Network Controller	Intel I217LM
Expansion Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1, 1 x PCI
Power Supply	280W or 450W
Operating System Support	Windows Server, Red Hat, SUSE, VMware
