Figure6“Drivebaylocations”onpage15showsthelocationsofthedrivebays.
Figure6.Drivebaylocations
1Primaryopticaldrivebay(alsocanbeusedtoinstallthefourthharddiskdrive)
2Secondaryopticaldrivebay(alsocanbeusedtoinstallatertiaryharddiskdrive)
3Secondaryharddiskdrivebay
4Primaryharddiskdrivebay
Chapter3.Productoverview15
