Figure 91. Disconnecting the mono amplifier cable
Step 3. Remove the mono amplifier.
a.
Remove the screw that secures the mono amplifier to the chassis.
b.
Slide out the mono amplifier from the bracket, and remove it from the chassis.
Figure 92. Removing the mono amplifier
After you finish
Chapter 3. Hardware replacement procedures 117
