Figure 100. Removing the screws securing power supply units to chassis
Step 4. Remove the power supply unit from the chassis.
a.
Press the release tab to disengage the power supply from the chassis.
b.
Slide out the power supply unit; then, lift it out of the chassis.
Figure 101. Removing the power supply unit
After you finish
130 ThinkSystem ST50 V2 Maintenance Manual
