The following illustration shows the connection of keys:
""-
W1
""+
""-
W2
""+
""-
W16
""+
""-
ON
OFF
""+
(not assigned)
19 red 1 black 2 white 3 grey 4 purple 5 blue 6 green 7 yellow 8 orange 9 red 10 brown 11 black 12 white 13 grey 14 purple 15 blue 16 green 17 yellow 18 orange 20 brown
2 keys for point
1
2 keys for point
2
2 keys for point
16
…and so forth
up to
2 keys for
NOTAUS / EIN
(emergency
shutdown /
startup)
(optional)
