40 Information LW150
The following illustration shows the connection of switches:
""-
ON
OFF
""+
""-
W1
""+
""-
W2
""+
""-
W16
""+
(not assigned)
19 red 1 black 2 white 3 grey 4 purple 5 blue 6 green 7 yellow 8 orange 9 red 10 brown 11 black 12 white 13 grey 14 purple 15 blue 16 green 17 yellow 18 orange 20 brown
Toggle switch
for point 1
Toggle switch
for point 2
Toggle switch
for point 16
… and so forth
up to
2 keys
NOTAUS / EIN
(emergency
shutdown /
startup)
(optional)
