The following table shows the assignment of the wire to the cathode
connection of the LED to the corresponding point:
Wire no.
Colour
Point
Wire no.
Colour
Point
1
black
1
9
red
9
2
white
2
10
brown
10
3
grey
3
11
black
11
4
purple
4
12
white
12
5
blue
5
13
grey
13
6
green
6
14
purple
14
7
yellow
7
15
blue
15
8
orange
8
16
green
16
Wire no.
Colour
17
yellow
The cathodes of two LEDs for indicating the
status AUS / EIN (ON / OFF) can be
connected to this wire.
18
orange
Not used
Use the following table for the anode connection (long wire) of the
LEDs:
Wire no.
Colour
19
red
Joint connection of the anode of the LEDs
for position "-" or "AUS"
20
brown
Joint connection of the anode of the LEDs
for position "+" or "EIN"
