Appendix
8-8
L
_^ONMObk
Code NoteName
C0150
*
Controller status word
(parameter channel) for:
Bit 820X 821X, 822X 8200 vector
Free configuration via C0417 (see
(
p
a
r
a
m
e
t
e
r
c
h
a
n
n
e
l
)
f
o
r
:
• 820X
F
r
e
e
c
o
n
f
i
g
u
r
a
t
i
o
n
v
i
a
C
0
4
1
7
(
s
e
e
Operating Instructions f or 8200
vector)
8
2
0
X
• 821X
• 8200 vector
• 822X
0 Reserved Actual parameter set
0= PS1active
1= PS2active
FREE 0 (free access)
(P2102)
1 IMP (pulse inhibit)
0 = Pulses for power stage enabled
1 = Pulses for power stage inhibited
2 I
max
(current limit reached)
0 = Current limit not reached
1 = Current limit reached
FREE 2 (free access)
3 Reserved f
d
= f
dset
(Act. frequency =
Frequency setpoint)
0=f
d
<> f
dset
1=f
d
=f
dset
FREE 3 (free access)
4 f
d
= f
dset
(Act. frequency =
Frequency setpoint)
0= f
d
<> f
dset
1= f
d
=f
dset
RFG on = RFG off
(RFG input = RFG output)
0 = RFG in < > RFG out
1 = RFG on = RFG off
FREE 4 (free access)
5 Q
min
(f
d
≤
f
dQmin
)
0= Q
min
not active
1= Q
min
active
FREE 5 (free access)
6 f
d
= 0 (act. frequency = 0)
0= f
d
<>0
1= f
d
=0
7 Ctrl. inhibit (controller inhibit)
0 = No controller inhibit
1 = Controller inhibit
8-11 Controller status
0 = No error
1 = Error
Controller status
0 = Unit initialisation
1 = Autostart lock
3 = Operation inhibited
4 = Flying-restart circuit active
5 = DC injection braking active
6 = Operation enable
7 = Message active (dynamically
set pulse inhibit, e.g. at OU)
8=Faultactive
Controller status
0 = Unit initialisation
1 = Autostart lock
3 = Operation inhibited
6 = Operation enable
7 = Message active (dynamically
set pulse inhibit, e.g. at OU)
8=Faultactive
9=Poweroff
12 Overtemperature warning ( J
max
-10°C)
0 = No controller inhibit
1 = Controller inhibit
Warning
0=Nowarning
1=Warning
13 U
Gmax
(DC-bus overvoltage)
0 = No overvoltage
1 = Overvoltage
Message
0 = No message
1 = Message
14 Direction of rotation
0 = CW rotation
1 = CCW rotation
FREE 14 (free access)
15 Ready for operation (no error, overvoltage or undervoltage)
0 = Not ready for operation
1 = Ready for operation
FREE 15 (free access)
The status word contains the most important status information in a compressed form.
LECOM format: VH
