CANopen
6 Parameter setting
6-34
L
BA2175 EN 2.0
6.4.1.12 1014
hex
: COB-ID emergency object
When errors occur in the 2175 fieldbus module or controller (e.g. TRIP), the CAN bus sends an error
message. The telegram is sent once for every fault.
Index [hex] Subindex Name Data typ e Authrorisation
1014 0 COB-ID emergency object U32 rw
Data telegram assignment
5th byte 6th byte 7th byte 8th byte
U32
0 10 11 - 28 29 30 31
11 bit identifier 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Reserved
Explanation
Bit no. Value Explanation
0-10 0/1 Identifier (see chapter 6.1.1)
(11 - 28)* 0
*
)
T
h
e
e
x
t
e
n
d
e
d
i
d
e
n
t
i
f
i
e
r
(
2
9
b
i
t
)
i
s
n
o
t
s
u
p
p
o
r
t
e
d
f
o
r
t
h
e
2
1
7
5
f
i
e
l
d
b
u
s
A
n
y
o
f
t
h
e
s
e
b
i
t
s
m
u
s
t
b
e
0
29* 0
*
)
The extended identifier (29 bit) is not supported for the 2175 fiel dbus.
A
ny of these bits must be 0.
30 0
R
e
s
e
r
v
e
d
31 0
Reserved
The “ emergency” telegram sent via CAN bus is structured as follows:
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8t h byte
Emergency error code
LENZE: Error code “10XX”
Error register
Object 1001
hex
Field for manufacturer-specific error messages
6.4.1.13 1015
hex
: Inhibit time emergency
This object determines the time between an internal module error and the sending of the error
message via the bus (“COB-ID emergency object” , code: 1014
hex
).
Only integer multiples of ten are processed further. The value entered is multiplied by 100, the result
isatimein[
µs].
Index [hex] Subindex Name Data typ e Authorisation
1015 0 Inhibit time emergency U16 rw
6.4.1.14 1018
hex
: Identity object
Entry of vendor-ID
Index [hex] Subindex Name Data typ e Authorisation
1018 0 ... 3 Identity Object Identity ro
The identification number for this object has been determined by “Organisation CAN in Automation
e. V.” and can be read out using this object:
Subindex Meaning
0 Highest subindex
1 V endor ID
2 Product code
3 Version
