Configuration
7-26
48XX/49XXSHB0399
Code Name
Possible settings
Lenze Selection Info
C116*¤ Input
selection:
Freely
assignable
digital
output
1 -1- FDO 1
-2- FDO 2
...
-12- FDO 12
-13- Relay output X3/K11, X3/K14
The digital outputs FDO1..FDO12 and the
relay output X3/K11, X3/K14 are freelay
assignable with the functions under C117.
Multiple assignment is possible.
The outputs FDO1...FDO5 are assigned to
the terminals X3/A1...X3/A5.
FDO6...FDO12 can only be accessed via
LECOM.
Assignment of functions:
1.Select output under C116.
2.Assign function under C117.
Only for FDO1...FDO5, relay output:
3.Determine polarity under C118.
4.Determine signal delay under C128.
[C117*] Function
for C116
-0- No function
-1- n
act
 n
x
C017 (FDO1)
-2- Controller enabled (FDO10)
-3- n-controller output = M
max
(FDO2)
-4- Ready for operation (RDY) (FDO11)
-5- Pulse inhibit (IMP) (FDO12)
-6- TRIP (relay)
-7- Warning (FDO6)
-8- Message (FDO7)
-9- Ramp function generator Input = Output
(FDO3)
-10- n
act
=n
set
(FDO5)
-11- n
act
=0(FDO4)
-12- I
A
=0(FDO8)
-13- I
A
&n
act
=0(FDO9)
-14- C046 or C049 >n
x
(Threshold C243)
-15- |I
A
|>I
x
(Threshold C244)
-16- I
F
>I
x
(Threshold C245)
-17- |n
act
|>n
x
(Threshold C242)
-18- Brake control
-19- Comparator 1
-20- Comparator 2
[C118] Polarity for
C116
-0- Output is HIGH active (FDO2, 3, 5)
-1- Output is LOWactive (FDO1, 4, relay)
C128* Delay for
C116
0.000 s 0.000 s {0.001 s} 240.000 s Signal delay times for FDO 1...5 and relay
output.
