Configuration
7-71
48XX/49XXSHB0399
Example
The analog inputs terminal 8 and terminal 6 are to be connected (division) via the
arithmetic block 2 and then be assigned to the code C046 ”main set-value”.
Procedure
( Select C145 = -4-, terminal 8
( Assign C146 = -14-, arithmetic block 2 input 1
( Select C145 = -3-, terminal 6
( Assign C146 = -15-, arithmetic block 2 input 2
( Select C145 = -10-, arithmetic block 2
( Assign C146 = -1-, main set-value (C046)
( C191 = -4-, division: select input 1 / input 2 (C338 / C339).
3. Functions
For all arithmetic blocks the following functions can be preselected (example for
arithmetic block 2):
with C191 = -0-, output = C338 (C339 not processed)
with C191 = -1-, output = C338 + C339
100% = 50% + 50%
with C191 = -2-, output = C338 - C339
50% = 100% - 50%
with C191 = -3-, output = C338
: C339
100% = 100%
: 100%
with C191 = -4-, output = C338 / |C339|
1% = 100% / 100%
with C191 = -5-, output = C338 / (100% - C339)
200% = 100% / (100% - 50%)
Arithmetic block 1 (fixed)
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C190*¤ Arithmetic
block 1
1 -0- Output = C046
-1- Output = C046 + C049
-2- Output = C046 - C049
-3- Output = C046 ¼ C049
-4- Output = C046 / |C049|
-5- Output = C046 / (100% - C049)
