Configuration
7-72
48XX/49XXSHB0399
Arithmetic block 2
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C191*¤ Arithmetic
block 2
1 -0- Output = C338
-1- Output = C338 + C339
-2- Output = C338 - C339
-3- Output = C338 ¼ C339
-4- Output = C338 / |C339|
-5- Output = C338 / (100% - C339)
C338* Input 1,
Arithmetic
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C339* Input 2,
Arithmetic
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145 / C146) is
assigned, the parameter will be displayed
only.
Arithmetic block 3
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C600*¤ Arithmetic
block 3
1 -0- Output = C601
-1- Output = C601 + C602
-2- Output = C601 - C602
-3- Output = C601 ¼ C602
-4- Output = C601 / |C602|
-5- Output = C601 / (100% - C602)
C601* Input 1,
arithmetic
block 3
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C602* Input 2,
arithmetic
block 3
0% -100.0 % {0.1 %} 100.0 %
-200 % {1%} +200 %
If an analog signal source (C145 / C146) is
assigned, the parameter will be displayed
only.
