7.8.4.2 Parameter change via two codes
Some setting are parameterised via two codes:
1. Select the parameter to be changed with the input selection
2. Change the parameter in the setting code.
Selection code for parameter input under
C025 Encoder C026 Encoder constant
C027 Encoder adjustment (factor)
C028 Encoder adjustment (divisor)
C029 Automatic adjustment
C038 JOG setpoint selection C039 JOG setpoint
C100 Additional accleration and deceleration time C101 Acceleration time
C103 Deceleration time
C110 Monitor output C111 Monitor signal
C108 Gain
C109 Offset
C112 Selection of freely assignable digital inputs C113 Function of the digital terminal
C114 Polarity
C115 Function priority
C116 Selection of freely assignable digital outputs C117 Function of the digital terminal
C118 Polarity
C128 Delay time
C145 Selection of freely assignable analog inputs C146 Signal input
C147 Priority
C192 Selection of freely assignable fixed setpoints C193 Fixed setpoints
Example “Automatic tacho adjustment”
Code level Parameter level
C 05 - -12
EN C OD E R
Code Parameter Unit
PRG
C 05 - -12
TE RMI NAL S 1 , 2
Code Parameter Unit
Change a parameter
with s or t
C 05 - -22
EN C OD E R
Code Parameter Unit
SH + PRG
C 05 -22
-
Code Parameter Unit
TE RMI NAL S 3 , 4
SelectacodewithV or W
.
C 092
AU T OM . E N C . A D J .
XX
rpm
XX
Code Parameter Unit
PRG
C 052YYYYrpm
AU T OM . E N C . A D J .
Code Parameter Unit
Change a parameter
with s or t
C 092
YYYrpm
Y
AU T OM . E N C . A D J .
Code Parameter Unit
SH + PRG
C 092
YYY Y r pm
AU T OM . E N C . A D J .
Code Parameter Unit
Parameter changed
