Configuration
7-124
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C043*¤ TRIP reset -0- Read: no fault
Write: reset fault
-1- Read: fault
Only selectable via the interfaces.
C045¤ JOG enable 0 -0- Main setpoint (C046) active
-1- Setpoint JOG1 active
...
-15- Setpoint JOG15 active
Displayonlywithterminalcontrol.
C046 n
set
speed -100.0 % n
max
{0.1 %} +100.0 % n
max
Display only with terminal control. If the
terminal control is deactivated, the actual
terminal value will be accepted for
operation.
C047 Torque limit -100.0 % M
max
{0.1 %} +100.0 % M
max
Display only with terminal control. If the
terminal control is deactivated, the actual
terminal value will be accepted for opera-
tion. Armature setting range: 100 % M
max
correspond to 100 % I
max
(C022, C023)
C049 Additional
setpoint
-100.0 % n
max
{0.1 %} +100.0 % n
max
Display: additional setpoint from terminal
C050 n
set
at controller -180.0 % n
max
{0.1 %} +180.0 % n
max
Display: speed setpoint at the input of the
speed controller
C051 n
act
speed -5000 rpm {1 rpm} + 5000 rpm Display: actual speed
C052* Motor voltage 0 V {1 V} 600 V Display: motor voltage V
A
C054 Motor current 0.0 A {0.1 A} 100 A
100 A {1 A} 2000 A
Display: motor current
C056 Torque setpoint -100.0 % M
max
{0.1 %} +100.0 % M
max
Display: Torque setpoint
Armature setting range: 100% M
max
correspond to 100% I
max
(C022, C023)
C060* Rotor position 0...2047 Display of the absolute angle position of
the rotor, standardized to 2048 incr./rev.
With incremental encoder feedback,
display only after zero track pulse
occured.
C061* I¼tload 0,0 % {0.1 %} 105,0% Display: ”I¼tload”
Starting value when switching on the
mainsisalways100% !
C063 I
set
at controller -100.0 % I
max
{0.1 %} +100.0% I
max
Display: current setpoint at current
controller input
