Lenze 4800 - Page 219

Configuration
7-128
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C088 Rated motor
current
0 A {0.1A} 100 A
100 A {1A} 3600 A
Rated current depends on the controller:
0..87A (4902)
0..135A (4903)
0..270A (4904)
0..450A (4905)
0..720A (4906)
0..900A (4907)
0..1200A (4X08)
0..1800A (4X09)
0..2520A (4X11)
0..3600A (4X12)
0..4050A (4X13)
See motor nameplate
C090¤ Rated motor
voltage
420 V 150 V {1 V} 650 V See motor nameplate
Observe max. permissible output voltage
of the controller!
C093*¤ Controller
identification
49XX Display: controller type
C094* User password 0 0 {1} 999 0 = No password protection (see also
C000)
C098 Language 0 -0- German
-1- English
-2- French
C099* Software
version
49 6.X Display: Series and software version
C100*¤ Input selection:
Additional
acceleration and
deceleration
times for main
setpoint
-1- Acceleration time T
ir1
/deceleration time T
if1
-2- Acceleration time T
ir2
/deceleration time T
if2
...
-15- Acceleration time T
ir15
/deceleration time T
if15
Extends T
ir
(C012) and T
if
(C013) by max.
15 value pairs. Can be changed under
C130:
1.Select additional times under C100.
2.Set under C101 (T
ir
) or C103 (T
if
).
C101* Acceleration
time for C100
0.00s 0s {0.01s} 1s
1 s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
Time refers to speed change 0...n
max
C103* Deceleration
time for C100
0.00s 0s {0.01s} 1s
1 s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
Time refers to speed change 0...n
max
C105 Deceleration
time for quick
stop
0.00s 0s {0.01s} 1s
1 s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
Time refers to speed change 0...n
max
C108* Gain for C110 1.00 -10.000 {0.001} + 10.000 Gain for X4/62, X4/63, X8
C109* Offset for C110 0mV -10000mV {1mV} + 10000mV Offset for X4/62, X4/63
Loading of the factory settings does not
overwrite C109.
This code is only effective if the digital
frequency output is selected under C110.
C110*¤ Input selection:
Monitor output
1 -1- Analog output X4/62 (monitor 1)
-2- Analog output X4/63 (monitor 2)
-3- Digital frequency output X8
The monitor outputs are freely assignable
with the signals under C111:
1.Select monitor output under C110.
2.Assign signals under C111.
3.If necessary, adjust under C108 and
C109.
