Configuration
7-130
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C112*¤ Input selection:
Freely
assignable
digital input
1 -1- digital input X2/E1
-2- digital input X2/E2
...
-5- digital input X2/E5
The digital inputs E1..E5 are freely
assignable with the functions under C113.
Each function can only be assigned to one
input. Exceptions:
l
C113 = -20- : max. 2 dig. inputs
l
C113 = -1-, -2-, -40-: max. 4 dig.
inputs (binary coded selection of max.
1, 3, 7 or 15 additional T
i
times or
setpoints).
Assignment of functions:
1.Select input under C112.
2.Assign function under C113.
3.Determine polarity under C114.
4.Determine priority under C115.
[C113*] Function for
C112
-0- No function
-1- Enable additional T
i
times
-2- Enable JOG setpoint (X4/E4, E5)
-3- TRIP reset (X2/E2)
-4- TRIP set (X2/E1)
-6- Switch-off additional setpoint (X4/E3)
-7- Switch-off I-component of the n-controller
-9- Ramp function generator stop
-10- Ramp function generator zero
-16 Motor potentiometer deactivated
-17 Motor potentiometer down
-18 Motor potentiometer up
-20 Select parameter set
-21 Load parameter set
-30- Deactivate process controller
-31- Switch-off I-component of the process
controller
-32- Set the process controller to 0
-40- Enable fixed setpoint
[C114*] Polarity for
C112
0 -0- Input HIGH active
-1- Input LOW active
[C115*] Priority for C112 -0- Terminal function not active, if terminal
control is switched-off under C001.
(X2/E4, E5)
-1- Terminal function remains active, if terminal
control is switched-off under C001.
(X2/E1, E2, E3)
C116*¤ Input selection:
Freely
assignable
digital output
1 -1- FDO 1
-2- FDO 2
...
-12- FDO 12
-13- Relay output X3/K11, X3/K14
The digital outputs FDO1..FDO12 and the
relay output X3/K11, X3/K14 are freely
assignable with the functions under C117.
Multiple assignment is possible.
The outputs FDO1...FDO5 are assigned to
the terminals X3/A1...X3/A5.
FDO6...FDO12 can only be accessed via
LECOM.
Assignment of functions:
1.Select output under C116.
2.Assign function under C117.
Only for FDO1...FDO5, relay output:
3.Determine polarity under C118.
4.Determine signal delay under C128.
