Configuration
7-134
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
[C146*] Function for
C145
-0- No function
-1- Main setpoint of C046
-2- Input for torque selection
-3- Additional setpoint of C049
-4- V
pn
of the speed controller
-5- Field current setpoint
-6- Process controller: setpoint (C330)
-7- Process controller: actual value
-8- Process controller: evaluation (C331)
-9- Process controller: ext. V
p
setting
-10- C027 of X5
-11- C027 of X9
-12- Gearbox factor (C032)
-13- Angle trimming of C256
-14- Speed trimming of C257
-15- Arithmetic block 2 - input 1 (C338)
-16- Arithmetic block 2 - input 2 (C339)
-17- Fixed setpoint block input
-18- Analog / digital conversion 1 (C270)
-19- Analog / digital conversion 2 (C271)
-20- Dead band element input (C622)
-21- DT1 element input (C652)
-22- Absolute value generator input (C660)
-23- Limiting element input (C632)
-24- PT1 element input (C641)
-25- Arithmetic block 3 - input 1 (C601)
-26- Arithmetic block 3 - input 2 (C602)
-27- Addition block 1 - input 1 (C610)
-28- Addition block 1 - input 2 (C611)
-29- Addition block 1 - input 3 (C612)
-30- Addition block 2 - input 1 (C614)
-31- Addition block 2 - input 2 (C615)
-32- Addition block 2 - input 3 (C616)
-33- Additional torque setpoint 1 (C148)
-34- Additional torque setpoint 2 (C149)
-35- FAI input of the S&H module
-36- AIF process controller: act. value
-37- Limiting element 2 input (C637)
-38- Comparator 1 input 1 (C580)
-39- Comparator 1 input 2 (C581)
-40- Comparator 2 input 1 (C590)
-41- Comparator 2 input 2 (C591)
-42- Input for ext. excitation characteristic
-43- n
act
of C051 (for tacho feedback)
-44- n
act
of C051 (for resolver or incremental
encoder feedback)
-46- Digital frequency setpoint
C146 = -4- V
pn
of the n-controller
corresponds to 0% at the input V
p2
under
C320 and 100% at the input V
pn
under
C070.
C146 = -5- field current setpoint
correspond to 100% at the input of the
rated current under C083. The minimum
adjustable value is determined under
C231.
C146 = -43-, -44-, -46- are for display
only (according to the configuration). They
cannot be assigned.
[C147*] Priority for C145 -0- Terminal function not active, if terminal
control is switched-off under C001.
-1- Terminal function remains active, if terminal
control is switched-off under C001.
