Configuration
7-135
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C148 Additional
torque value 1
0 -100.0 % M
max
{0.1%} + 100.0 % M
max
-200 % M
max
{1%} + 200 % M
max
Display only with terminal control. If the
terminal control is deactivated, the actual
terminal value will be accepted for
opera tion. Armature setting range: 100 %
M
max
correspond to 100 % I
max
(C022,
C023)
C149 Additional
torque value 2
0 -100.0 % M
max
{0.1%} + 100.0 % M
max
-200 % M
max
{1%} + 200 % M
max
Display only with terminal control. If the
terminal control is deactivated, the actual
terminal value will be accepted for
opera tion. Armature setting range: 100 %
M
max
correspond to 100 % I
max
(C022/C023)
C151* FDO
Status
Bit Free digital output
0FDO1
...
11 FDO 12
12 Relay output
C151 indicates the states of the digital
outputs as decimal or binary values. The
polarity reversal under C118 is not
considered.
[C180*] 4Q/2Q
operation
-0- 4Q operation (49XX)
-1- 2Q operation (48XX)
Important for controller type 48XX:
Controllers must only be operated with
C180 = -1-!
Fault PR sets C180 = -0-. It is absolutely
necessary to set C180 = -1- before
commissioning.
C182* T
i
time of the
S-shape
ramp function
generators
20.0 s 0.01 s {0.01s} 1 s
1s {0.1s} 10s
10s {1s} 50s
T
i
time for the S-shape ramp function
generator of the main setpoint
C183 Origin of
controller inhibit
Display Origin of ctrl inhibit
Terminal or term. Terminal
Keypad or kp Keypad (STP key)
LECOM1 or L1 LECOM1 interface
Aut.int. (AIF) Automation / fieldbus interface
(module, InterBus, PROFIBUS, ...)
oth. src. Other source
or o.s. Release: TRIP or message
Information: C065, C067
Display: Source which has inhibited the
controller
C185 Motor power -500.0 kW {0.1 kW} 500.0 kW Display: actual motor power
C186 Motor torque -999 Nm {1 Nm} 999 Nm Display: actual motor torque
C187 Field current
setpoint
0.00 A {0.01 A} 50.0 A Display: actual field current setpoint
C188 Actual field
current
0.00 A {0.01 A} 50.0 A Display: actual field current value
C189 Mains
frequency
0.0 Hz {0.1 Hz} 100.0 Hz Display: actual mains frequency
C190*¤ Arithmetic
block 1
1 -0- Output = C046
-1- Output = C046 + C049
-2- Output = C046 - C049
-3- Output = C046 ¼ C049
-4- Output = C046 / |C049|
-5- Output = C046 / (100% - C049)
C191*¤ Arithmetic
block 2
1 -0- Output = C338
-1- Output = C338 + C339
-2- Output = C338 - C339
-3- Output = C338 ¼ C339
-4- Output = C338 / |C339|
-5- Output = C338 / (100% - C339)
