Configuration
7-136
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C192*¤ Input selection:
Fixed setpoint
1 -1- Selection fixed setpoint 1
-2- Selection fixed setpoint 2
...
-15- Selection fixed setpoint 15
It is possible to set up to 15 setpoints with
freely selectable references:
1.Select fixed setpoint under C192.
2.Assign value under C193.
3.Enable via the digital inputs or C194.
C193* Setpoint for
C192
-100.0 % {0.1 %} +100.0 %
100.0% Fixed setpoint 1
75.0% Fixed setpoint 2
50.0% Fixed setpoint 3
25.0% Fixed setpoint 4
0.0% Fixed setpoint 5
...
0.0% Fixed setpoint 15
C194*¤ Enable fixed
setpoint
0 -0- Free input is active
-1- Fixed setpoint 1 is active
...
-15- Fixed setpoint 15 is active
C195* Delay
between
’engage brake’
and controller
inhibit
9999 s 0.00s {0.01 s} 1s
1s {0.1s} 10s
10s {1s} 250s
9999 s
Delay between signal ’engage brake’ and
automatic controller inhibit
9999 s:
Unlimited delay, controller will not be
inhibited.
C196* Delay between
’setpoint
integrator free’
and quick stop
0.00s 0.00 s {0.01 s} 1 s
1s {0.1s} 10s
10s {1s} 100s
100s {10s} 250s
Delay between reset of the quick stop
function and enable of the main setpoint
integrator
[C197*] Sign of the
torque selection
0 -0- Sign is determined by the torque setpoint
-1- positive sign
-2- negative sign
Sign of the torque selection between reset
of QSP and enable of the setpoint
integrators
[C198*] Enable actual
speed filter
0 -0- Filter not active
-1- Filter active
C199* Time constant
act. speed filter
10ms 8ms {1ms} 100ms
C200* Software
identification
String format: ”33S4902M_61000” Display of the software version only via
interface.
C220* Acceleration
time T
ir
of the
additional
setpoint
0.00 s 0.00 s {0.01 s} 1 s
1s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
C221* Deceleration
time T
if
of the
additional
setpoint
0.00 s 0.00 s {0.01 s} 1 s
1s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
C222* V
p
process
controller
1 0.1 {0.1} 10
10 {1.0} 500
Gain of the process controller
[C223*] T
n
process
controller
400 ms 20 ms {1ms} 20000 ms
9999 ms
T
n
= 9999 ms: I-component switched-off
(only when controller is inhibited)
C224* K
d
process
controller
0.0 0.0 ¼ V
pn
{0.1 ¼ V
pn
}5.0¼ V
pn
Differential component of the process
controller
[C230*] Control mode
for the override
field control
0 -0- Limitation of the armature voltage
-1- Control of the armature voltage
Field weakening must be permitted under
C231.
