Configuration
7-140
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C320* V
p2
of the n-
controller
adaption
8 1 {1} 1000 Second gain factor for speed controller
adaption
C321* V
p3
of the n-
controller
adaption
8 1 {1} 1000 Third gain factor for speed controller
adaption
C322* n
1
of the n-
controller
adaption
3000
rpm
0 rpm {1 rpm} 5000 rpm Speed setpoint threshold of speed
controller adaption, condition: n
1
>n
0
C323* n
0
of the n-
controller
adaption
50 rpm 0 rpm {1 rpm} 5000 rpm Speed setpoint threshold of speed
controller adaption, condition: n
1
>n
0
C324*¤ n-controller
adaption on/off
0 -0- n-controller adaption is off
-1- n-controller adaption is on
C325* V
p2
of the
process
controller
adaption
1 0.1 {0.1} 10
10 {1} 500
Second gain factor for process controller
adaption
C326* V
p3
of the
process
controller
adaption
1 0.1 {0.1} 10
10 {1} 500
Third gain factor for process controller
adaption
C327* set2 of the
process
controller
adaption
100 % 0.0 % {0.1 %} 100.0 % Setpoint speed threshold of the process
controller adaption, condition: set2 > set1
C328* set1 of the
process
controller
adaption
0% 0.0 % {0.1 %} 100.0 % Setpoint speed threshold of the process
controller adaption, condition: set2 > set1
C329*¤ Process
controller
adaption on/off
0 -0- Process controller adaption is off
-1- Process controller adaption is on
C330* Setpoint of the
process
controller
0% -100.0 % {0.1 %} 100.0 % If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C331* Evaluation of
the process ctrl.
output
100 % -100.0 % {0.1%} 100.0 % If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C332* Acceleration
time T
ir
of the
process
controller
setpoint
0.00 s 0.00 s {0.01 s} 1.00 s
1.0 s {0.1 s} 10.0 s
10 s {1 s} 100 s
100 s {10 s} 990 s
C333* Deceleration
time T
if
of the
process ctrl.
setpoint
0.00 s 0.00 s {0.01 s} 1.00 s
1.0 s {0.1 s} 10.0 s
10 s {1 s} 100 s
100 s {10 s} 990 s
C334* Acceleration
time T
ir
of the
process ctrl.
evaluation
0.00 s 0.00 s {0.01 s} 1.00 s
1.0 s {0.1 s} 10.0 s
10 s {1 s} 100 s
100 s {10 s} 990 s
C335* Deceleration
time T
if
of the
process ctrl.
evaluation
0.00 s 0.00 s {0.01 s} 1.00 s
1.0 s {0.1 s} 10.0 s
10 s {1 s} 100 s
100 s {10 s} 990 s
