Configuration
7-141
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C336* Actual V
p
of the
process
controller
0.1 {0.1} 500.0 Display: Actual gain factor of the process
controller (important for process controller
adaption)
C338* Input 1,
arithmetic
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 %{1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C339* Input 2,
arithmetic
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C370*¤ Enable
automation
interface
-0- No communication via automation interface
-1- Communication via automation interface
enabled
C380* n
set
speed -16384 {1} 16384 High precision main setpoint selection:
16384  100% under C046
Input only via interface.
C381* n
set
at
n-controller
-32767 {1} 32767 High precision setpoint display:
Input of the speed controller,
16384  100% under C050.
Input only via interface.
C382* Actual speed -32767 {1} 32767 High precision display: Act. speed value
16384  n
max
under C011.
Input only via interface.
C387* Torque limit -16384 {1} 16384 High precision torque setpoint selection:
16384  100% under C047.
Input only via interface.
C388* Torque setpoint -16384 {1} 16384 High precision torque setpoint display:
16384  100% under C056.
Input only via interface.
C391* Actual angle 0 {1} 65535 High precision display of the actual angle
if resolver or incremental encoder operate
as feedback system:
16384  3601 revolution.
Input only via interface.
C392* Field current
setpoint
0 {1} 16384 High precision display of the field current
setpoint:
16384  I
FN
under C083.
Input only via interface.
C393* Additional
setpoint
-16384 {1} 16384 High precision additional setpoint display:
16384  100% under C049.
Input only via interface.
C580* Input 1,
comparator 1
0% -100.0 % {0.1 %} + 100.0 %
-200 % {1 %} + 200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C581* Input 2,
limit value for
comparator 1
0% -100.0 % {0.1 %} + 100.0 %
-200 % {1 %} + 200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C582* Hysteresis for
lower threshold
comparator 1
0% 0.0 % {0.1 %} + 100.0 % Lower threshold = C581 - C582,
reference: C581
C583* Memory
function
comparator 1
-0- Memory function not active
when resetting the output, the value falls below
the lower threshold (C581 - C582)
-1- Memory function active
The output remains set after inital switching
on.
C584*¤ Reset function
comparator 1
-0- Reset function not active
-1- Reset function active
The activation resets the output.
