Configuration
7-142
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C590* Input 1,
comparator 2
0% -100.0 % {0.1 %} + 100.0 %
-200 % {1 %} + 200 %
If an analog signal source (C145/C146) is
assigned, only the parameter will be
displayed.
C591* Input 2,
limit value for
comparator 2
0% -100.0 % {0.1 %} + 100.0 %
-200 % {1 %} + 200 %
If an analog signal source (C145/C146) is
assigned, only the parameter will be
displayed.
C592* Hysteresis for
lower threshold
comparator 2
0% 0.0 % {0.1 %} + 100.0 % Lower threshold = C591 - C592,
reference: C591
C593*¤ Memory
function
comparator 2
-0- Memory function not active
when resetting the output, the value falls
below the lower threshold (C591 - C592)
-1- Memory function active
The output remains set after inital switching
on.
C594*¤ Reset function
comparator 2
-0- Reset function not active
-1- Reset function active
The activation resets the output.
C600*¤ Arithmetic
block 3
1 -0- Output = C601
-1- Output = C601 + C602
-2- Output = C601 - C602
-3- Output = C601 ¼ C602
-4- Output = C601 / |C602|
-5- Output = C601 / (100% - C602)
C601* Input 1,
arithmetic
block 3
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C602* Input 2,
arithmetic
block 3
0% -100.0 % {0.1 %} 100.0 %
-200 % {1%} + 200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
