Configuration
7-143
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C610* Input 1, addition
block 1
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C611* Input 2, addition
block 1
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C612* Input 3, addition
block 1
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C614* Input 1, addition
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C615* Input 2, addition
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C616* Input 3, addition
block 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C620* Gain dead band
element
1.00 -10.00 {0.01} +10.00
C621* Dead band,
dead band
element
1.0 % 0.0 % {0.1 %} 100.0 %
C622* Input, dead
band element
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
Display parameter only
C630* Limiting
element 1
upper limit
100 % -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
C630 must be higher than C631!
C631* Limiting
element 1
lower limit
-100 % -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
C631 must be lower than C630!
C632* Input, limiting
element 1
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
Display parameter only
C635* Limiting
element 2
upper limit
100 % -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
C635 must be higher than C636!
C636* Limiting
element 2
lower limit
-100 % -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
C636 must be lower than C635!
C637* Input, limiting
element 2
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
Display parameter only
C640* PT1 element
Time constant
20ms 0.01 s {0.01 s} 1 s
1s {0.1s} 10s
10s {1s} 50s
