Configuration
7-144
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C641* Input,
PT1 element
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
Display parameter only
C650* Gain
DT1 element
1.00 -10.00 {0.01} +10.00
C651* DT1 element
Time constant
1.0 s 0.01 s {0.01 s} 1.00 s
1.0 s {0.1 s} 5.0 s
C652* Input,
DT1 element
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} + 200 %
Display parameter only
C653* Input sensitivity,
DT1 element
-1- 15 bit evaluation
-2- 14 bit evaluation
-3- 13 bit evaluation
-4- 12 bit evaluation
-5- 11 bit evaluation
-6- 10 bit evaluation
-7- 9 bit evaluation
C660* Input,
absolute value
generator
0% -100.0 % {0.1 %} 100.0 %
-200 % {1 %} +200 %
Display parameter only
C670* Square
generator
upper limit
0% -100.0 % {0.1 %} +100.0 % C670 must be higher than C671!
C671* Square
generator
lower limit
0% -100.0 % {0.1%} + 100.0 % C671 must be smaller than C670!
C672* Switch-over
time of the
square
generator
0.1 s 0.1 s {0.1 s} 10.0 s
10 s {1 s} 100 s
100 s {10 s} 3000 s
