Selection aid
15-5
48XX/49XXSHB0399
Parameter setting
Code Input Description
Input according to motor nameplate
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Input of current limits
C022, C023 xxx A Maximum motor current
Enter controller configuration
C000 -2- Extended code set
C005 -12- Speed control with resolver feedback
Adjustment of speed controller
C011 xxxx rpm Max. max. speed
Application parameters
C019 xxxx rpm Set threshold n
act
=0
C070 V
pn
At high inertia, adapt n - controller gain V
pn
Save parameter
C003 Save parameter set
